What gauge are the corrugated metal fence sheets?
26-gauge galvanized steel, formed into a 7/8" corrugated wave. The wave adds stiffness, so a light sheet holds a straight line between rails without bowing.
Which lengths do the corrugated sheets come in?
All sheets are 38" wide (37.75" actual) and come in 45", 57", 69", 81" or 93" lengths. The 57" sheet fits a 5' fence and the 81" sheet fits a 7' fence.
How many corrugated sheets do I need for my fence?
Each sheet covers about 36" of width after a one-corrugation overlap. Divide your run in feet by 3 and round up for the sheets in each row.
Do you cut corrugated sheets to other lengths?
Yes. Order custom corrugated metal fence sheets and we'll make them to your length.
Which colours are available for the sheets?
Black, Grey, Brown and Corten Steel, matching the colours on our framed corrugated panels.
Are the painted sheets the same colour on the back?
Yes. Black, Grey and Brown carry HDP paint on both faces, so it doesn't matter which side faces out.
How does a Corten corrugated sheet change outdoors?
It starts a dull blue-grey and weathers to orange, then deep brown, over several weeks to a few months. Rust runoff can stain concrete or pavers until the patina settles, which is normal for weathering steel and not a defect.
Can I install corrugated sheets horizontally?
Yes. Since you're building the frame, the wave can run either direction. For horizontal sheets, add blocking so both long edges get fastened.
What screws should I use on corrugated fence sheets?
Coated self-drilling metal-panel screws with rubber washers, driven through the crest of the wave. Overlap each sheet one corrugation and point the seam away from the prevailing wind.
Should I cut the sheets to fit?
It's better to pick a stock or custom length that fits your frame. Grinding throws sparks that can scorch the paint, and a cut edge is bare steel that isn't covered by the warranty.
Can I buy the sheets already framed?
Yes. The treated wood corrugated metal fence panels and cedar and corrugated metal fence panels are built with these same sheets.
How long is the warranty on corrugated sheets?
40 years on the steel and its finish.
How are the corrugated sheets shipped?
On BarrierBoss trucks to BC, Alberta, Saskatchewan and Manitoba, unloaded on site by our crew. The estimate box prices delivery once you add your postal code.
Most projects fit the sizes listed on this page — those are what we build, stock and price online.
We do make custom sizes within our standard range, and we quote them case by case. If your run falls between two listed sizes — say you need 7′ 6″ when we list 7′ and 8′ — we can build it. The cost depends on the dimensions, the profile and how much material the cut leaves behind, so custom sizes are not listed or priced on the site. Send us the measurements and we will tell you what is possible and what it costs.
Custom sizes are final sale. A panel cut to your dimensions cannot be restocked or sold to anyone else, so custom-sized orders cannot be returned or exchanged. Please confirm your measurements before you approve the quote.
These products can all be modified on site. Trimming a panel to close out a run is normal work, and you do not need us to do it for you — ask and we will walk you through how to cut and seal it properly so the finish holds up.
Just know that a cut edge is no longer a factory edge: cutting or drilling exposes unprotected steel and voids the steel & coating warranty on that component. Done the right way and sealed properly it will still last — so ask us before you cut.
- Standard-size items (unused, original condition) — returnable within 30 days, subject to a 25% restocking fee. We pick returns up on our own trucks (scheduled around truck availability), at no return-freight charge to you. Because we handle the transport, you're not liable for any transit damage.
- Custom, cut-to-size & made-to-order items — because these are built to your exact spec, they are final sale.
- Cancellations — full refund before your order enters production; once in production or scheduled to ship, a 25% restocking fee applies.
- Damaged or defective on arrival — fully covered. Every shipment is freight-insured end to end, so anything that arrives damaged is replaced or refunded at no cost — you're never on the hook for transit damage.
